CAD DrawingCAD Drawing 2CAD Drawing 3Lumitec Maxillume H60 Trunnion
White LED Flush Mount
Model: 101347The new Maxillume h120 is poised to set a new standard in DC powered LED flood lighting. Delivering more than 12,000 TRUE lumens and housed in powder coated heavy duty aluminum housing, this light is engineered to work hard. Designed to replace the ubiquitous GE "QF" series of quartz floodlights, tested to withstand vibration and shock and completely water sealed (IP67 compliant). The Maxillume h120 is the ultimate in LED flood lighting, built for the most extreme conditions and toughest of jobs. Each light is designed, hand assembled and tested at our USA manufacturing facility.
Specifications| Lumens (White) | 12000 |
| Voltage | 10-30vDC |
| 12v DC Amps | 10A |
| 24v DC Amps | 5A |
| Rated Watts | 120 |
| CCT | 5000 |
| CRI | 70+ |
| Op. Temp F/C | -31/35 to + 131/55 |
| Timed Toggled Protocol (TTP) | Yes |
| Third Party Dimmer Compatibility | No |
| Color Match Commitment (CM) | Yes |
| Mounting Hole Diameter | N/A |
| Height | 8in (20.32cm) |
| Width | 6in (15.24cm) |
| Depth | 3.32in (8.43cm) |
| Diameter | N/A |
