NSS7 evo3 7" Chartplotter/Fishfinder MFD
Navigate, take control, and enjoy an unprecedented level of built-in functionality with NSS evo3. SolarMAX HD display technology offers exceptional clarity and ultra-wide viewing angles, combined with an all-weather touchscreen and expanded keypad for total control in all conditions. Cruise confidently with ForwardScan sonar, or fish easier with StructureScan® HD imaging and dual-channel CHIRP-enabled Broadband Sounder technology. Built-in Wi-Fi enables access to GoFree® online services, and delivers smartphone monitoring and tablet control to extend your display's reach well beyond the helm. The NSS7 evo3 features a 7-inch display perfect for centre consoles and other installations where space is at a premium. Includes Insight charts.- 7-inch widescreen SolarMAX HD display.
Product : SIMRAD NSS7 EVO3 COMBO MFD NO TRANSDUCER
Manufacturer : SIMRAD
Manufacturer Part No : 000-13233-001
Navigate, take control, and enjoy an unprecedented level of built-in functionality with NSS evo3. SolarMAX HD display technology offers exceptional clarity and ultra-wide viewing angles, combined with an all-weather touchscreen and expanded keypad for total control in all conditions. Cruise confidently with ForwardScan sonar, or fish easier with StructureScan® HD imaging and dual-channel CHIRP-enabled Broadband Sounder technology. Built-in Wi-Fi enables access to GoFree® online services, and delivers smartphone monitoring and tablet control to extend your display's reach well beyond the helm. The NSS7 evo3 features a 7-inch display perfect for centre consoles and other installations where space is at a premium. Includes Insight charts.- 7-inch widescreen SolarMAX HD display.
- Reliable control in all conditions: switch seamlessly between multi-touch and a full keypad with rotary dial
Integrated echosounder featuring dual-channel CHIRP, ForwardScan® sonar, and StructureScan® HD imaging - Add StructureScan® 3D imaging, advanced Broadband Sounder capabilities and more via Simrad modules
- Expand your view with Halo™ Pulse Compression radar, Broadband 3G™/4G™, and other Simrad radar solutions
- Take complete control of Simrad autopilot systems with the NSS evo3 touchscreen or keypad
- NMEA 2000® connectivity enables integrated engine monitoring, sound system control, and much more
- Navigate accurately with an embedded high-gain 10 Hz GPS/GLONASS receiver
- Enjoy easier trip planning with TripIntel technology and support for
- Navionics Autorouting/C-MAP Easy Routing (automatic routing unavailable in North America)
- Built-in GoFree Wi-Fi enables online features and smartphone monitoring/tablet control
- Choose flush-mount installation for a low-profile Glass Bridge look, or bracket-mount to install almost anywhere
- Includes Insight chart
- Dimensions without bracket and knobs: 9.41"w x 5.90H
- Dimensions with brack and knbos: 10.35"w x 6.31"h
Product : SIMRAD NSS7 EVO3 COMBO MFD NO TRANSDUCER
Manufacturer : SIMRAD
Manufacturer Part No : 000-13233-001
