Blue Sea 187-series 70 Amp Circuit Breaker Panel Mount

Blue Sea 187-series 70 Amp Circuit Breaker Panel Mount

No reviews yet Write a Review
$67.49
SKU:
WTBSS7041
UPC:
632085070410
Weight:
0.50 LBS
DOWNLOADS
Product PDF
Spec Sheet PDF
CAD Drawing
CAD Drawing 2
CAD Drawing 3

Blue Sea Systems 187-Series Circuit Breaker - Panel Mount 70A

Model: 7041-BSS
  • Combines switching and circuit protection into a single device*
  • Clear, single lever operation
  • ""Trip Free"" design cannot be held ""ON"" during fault current condition
  • Waterproof
  • Recessed mounting holes for clean appearance
  • Large Clearance around terminal studs accept heavy gauge wire lugs
  • Robust 5/16 M8 terminals provide high torque connections
  • Large lever with vertical/horizontal orientation provides indication of trip status
  • Ignition protected - Safe for installation aboard gasoline powered boats

* Do not use as a switch where high inrush currents are expected.

Specifications
Amperage70A
Maximum Voltage48vDC
MountingPanel Mount
Circuit Breaker TypeThermally responsive Bi-metal blade
Terminal Stud Torque75 in-lb (8.47 Nm)
Interrupt Capacity5000A @ 12V
3000A @ 24V
1500A @ 42V
Minimum Operating Temperature-40° C
Maximum Operating Temperature85° C
Case MaterialThermoset Polyester
Circuit Breaker ClassType III - switchable/manual reset - trip free
Mounting HoleAccept #10 (M5) Screw
Terminal Stud Size5/16"" - 18
