CAD DrawingCAD Drawing 2CAD Drawing 3Oval Surface Mount USB 3.0 & USB-C Power Socket
This oval surface-mount USB 3.0 & USB-C power socket charges two devices simultaneously. When split, the total 6A output is 3A per side. USB 3.0 features quick charging (QC) for supported devices, giving enough power to charge phones, pads, and tablets quickly and efficiently.
Features:
- USB-C features Power Delivery (PD) for faster and more flexible charging
- A protective dust cap covers the ports when not in use. Constructed of injection-molded nylon
- Easy installation requires drilling a 3/16" hole for the wire connection, securing it to the surface with two #6 screws (not included), and snapping the concealed fastener cover in place
- Blue LED illumination
- IP65 rating
- CE and RoHS compliant
Specifications:
- Diameter (inch): 2-3/8"
- Height (inch): 1-15/16"
- Width (inch): 3/4"
- Volts: 8-32
- Total Output: 5V/6A
- USCB-C Watts: 60W @ 24V
- USB-A Watts: 36W @ 12V
- Weight: 0.07 lb.
- Color: Black
Manufacturer : Sea-Dog
Manufacturer Part No : 426535-1
